ERFURT PE2-800 – 800 Ton Mechanical Press – 3950 x 1780 mm

ERFURT PE2-800, 800 ton double-column mechanical press.

Heavy-duty press with 3950 x 1780 mm slide and fixed table, 500 mm stroke, 800 mm daylight and variable speed from 8 to 12 spm.

Main specifications:

• Model: PE2-800

• Capacity: 800 ton

• Slide stroke: 500 mm

• Daylight: 800 mm

• Slide adjustment: 200 mm

• Slide dimensions: 3950 x 1780 mm

• Table dimensions: 3950 x 1780 mm

• Table type: Fixed

• Speed: 8–12 spm

• Cushion: Yes

• Front clearance between uprights: 4050 mm

• Side clearance between uprights: 1000 mm

• Approx. press weight: 160 ton
