2019 MOSSINI PDM/4B/LD/2000

MODELLO - TYPE                                                            : PDM/4B/LD/2000

MATRICOLA-SERIAL NUMBER                                        : 0965/19

CINEMATISMO- KINEMATICS                                         : LINK DRIVE

CAPACITA’- RATED CAPACITY AT 13mm                      : 2000 Tons

PUNTI di Spinta -NUMBER of connecting rod                : 4

CORSA SLITTA - SLIDE STROKE                                       : mm 900

REGOLAZIONE SLITTA- SLIDE ADJUSTMENT                     : mm 400

VELOCITA’ CONTINUA (variabile)

CONTINUOUS SPEED (variable)                                    : spm 10 - 25

LUCE VERTICALE dal carrello portastampi, CBRA

SHUT HEIGHT, from top of bolster, SDAU                       : mm 1270

DIMENSIONI SLITTA SLIDE DIMENSIONS (L-R x F-B)         : 6000 X 2500 mm

DIMENSIONI MOVIN BOLSTER LATERALE (dx-sx x fronte-retro)

SIDE MOVING BOLSTER DIMENSIONS (L-R x F-B)            : 6000 X 2500 mm

DIMENSIONI PRINCIPALI-MAIN DIMENSIONS

APERTURA tra I MONTANTI frontale (dx-sx)

CLEARANCE BETWEEN UPRIGHTS (L-R)                          : 6070 mm

APERTURA tra I MONTANTI LATERALE (fronte-retro)

CLEARANCE BETWEEN UPRIGHTS (F-B)                          : mm 3300

ALTEZZA CARRO MOBILE-MOVING BOLSTER H.       : mm 550

PESO DELLA PRESSA-WEIGHT OF THE PRESS                    : Kg.600.000
