2016 MOSSINI PDM/2B/LD/630

MODELLO - TYPE                                                            : PDM/2B/LD630

MATRICOLA-SERIAL NUMBER                                        : 0928/16

ANNO/YEAR                                                                 : 2016

CINEMATISMO- KINEMATICS                                         : LINK DRIVE

CAPACITA’- RATED CAPACITY AT 13 mm                     : 630 Tons

PUNTI di Spinta -NUMBER of connecting rod                : 2

CORSA SLITTA - SLIDE STROKE                                       : mm 400

REGOLAZIONE SLITTA- SLIDE ADJUSTMENT                     : mm 500

VELOCITA’ CONTINUA (variabile)

CONTINUOUS SPEED (variable)                                    : spm 24 - 53

LUCE VERTICALE dal carrello portastampi, CBRA

SHUT HEIGHT, from top of bolster, SDAU                       : mm 1200

DIMENSIONI SLITTA SLIDE DIMENSIONS (L-R x F-B)         : 3200 X 1200 mm

DIMENSIONI MOVIN BOLSTER LATERALE

SIDE MOVING BOLSTER DIMENSIONS                            : 3200 X 1200 mm

DIMENSIONI PRINCIPALI-MAIN DIMENSIONS

APERTURA tra I MONTANTI frontale (dx-sx)

CLEARANCE BETWEEN UPRIGHTS (L-R)                          : 3300 mm

APERTURA tra I MONTANTI LATERALE (fronte-retro)

CLEARANCE BETWEEN UPRIGHTS (F-B)                          : mm 1700

ALTEZZA CARRO MOBILE-MOVING BOLSTER H.       : mm 500

PESO DELLA PRESSA-WEIGHT OF THE PRESS                    : Kg.155.000
