NAVA 360 Ton Hydraulic Press – 2400 x 1600 mm

NAVA 360 ton hydraulic press, model 2MI360/140.

Heavy-duty hydraulic press equipped with a 2400 x 1600 mm ram and table, 1000 mm slide stroke, 1565 mm maximum opening and 140 ton cushion.

Main specifications:

• Manufacturer: NAVA

• Model: 2MI360/140

• Serial number: 834--

• Capacity: 360 ton

• Slide stroke: 1000 mm

• Ram size: 2400 x 1600 mm

• Table size: 2400 x 1600 mm

• Maximum opening: 1565 mm

• Cushion capacity: 140 ton

• Cushion stroke: 400 mm

• Installed power: 130 HP

• Approx. press weight: 58,000 kg

Suitable for hydraulic forming, deep drawing and general sheet metal applications.

Available from GENTA Presses.
