NAVA 630 Ton Hydraulic Press – 3200 x 2200 mm

NAVA 630 ton hydraulic press, model 2MI630/300.

Heavy-duty hydraulic press equipped with a large 3200 x 2200 mm ram and table, 1100 mm slide stroke, 2000 mm maximum opening and 300 ton cushion.

Main specifications:

• Manufacturer: NAVA

• Model: 2MI630/300

• Serial number: 747--

• Capacity: 630 ton

• Slide stroke: 1100 mm

• Ram size: 3200 x 2200 mm

• Table size: 3200 x 2200 mm

• Maximum opening: 2000 mm

• Cushion capacity: 300 ton

• Cushion stroke: 500 mm

• Installed power: 290 HP

• Approx. press weight: 165,000 kg

• Height above floor: 7000 mm

Suitable for deep drawing, heavy sheet metal forming and large industrial applications.

Available from GENTA Presses.
